NEW ATS Power SP50 Hydraulic Shop Press Specifications

The ATS Power SP50 is a heavy-duty 50-ton air/hydraulic shop press designed for automotive repair, machine shops, farm maintenance, and fabrication work. It is built with a fully welded H-frame and offers both manual and pneumatic operation.

Press Capacity

• Pressing Capacity: 50 Tons
• Operation: Air/Hydraulic and Manual
• Air Pressure Requirement: 110–125 PSI
• Cylinder Bore: 3.5 inches
• Ram Stroke: 7.5 inches
• Pressure Gauge: 4-inch oil-filled gauge for monitoring pressing force.

Dimensions

• Overall Length: 51 inches
• Overall Width: 28 inches
• Overall Height: 68 inches
• Bed Width: 27.5 inches
• Bed Depth: 7.75 inches
• Upright Opening: 41 inches.

Construction

• Frame Type: Fully welded heavy-duty H-frame
• Hydraulic Cylinder: Dual-operation cylinder (manual and air-powered)
• Construction: Heavy-gauge steel
• Designed for high-load pressing and long service life.

Weight

• Shipping Weight: Approximately 540 lbs
• Heavy-duty floor-standing design for stability during pressing operations.

Common Applications

✅ Bearing installation and removal
✅ Bushings and seals
✅ U-joint replacement
✅ Gear and pulley removal
✅ Straightening and bending metal
✅ Press-fit components and fabrication work.
